Oniro Emulator

The Oniro Emulator provides an easy and accessible way to develop and test applications or system components without the need for physical hardware.
It is based on QEMU, a powerful open-source machine emulator and virtualizer.
The emulator uses the x86_64 architecture, which, when run on an x86 host PC, enables faster emulation by leveraging KVM on Linux and Hyper-V on Windows for hardware-assisted virtualization.

This guide provides step-by-step instructions to build and run the Oniro Emulator.

Oniro Emulator

📦 Prerequisites

Before proceeding, make sure you have followed the Quick Build Setup guide to prepare your build environment.

⬇️ Download Oniro Source Code

Use the following commands to fetch the Oniro source:

repo init -u https://github.com/eclipse-oniro4openharmony/manifest.git -b OpenHarmony-5.0.2-Release -m oniro.xml --no-repo-verify
repo sync -c
repo forall -c 'git lfs pull'

🧰 Switch to Required Kernel Version

Replace the default kernel with the required version:

rm -rf kernel/linux/linux-6.6
git clone -b weekly_20241216 https://gitee.com/openharmony/kernel_linux_6.6.git kernel/linux/linux-6.6 --depth=1

🩹 Apply source patches

Run the patching script:

bash vendor/oniro/std_emulator/hook/hook_start.sh

🛠️ Build the images

Start the build with ccache enabled:

./build.sh --product-name std_emulator --ccache

🔄 (Optional) Revert patches

If needed, you can undo the applied patches:

bash vendor/oobemulator/std_emulator/hook/hook_end.sh

📥 Download Prebuilt Images

Alternatively, you can download the prebuilt Oniro Emulator images.

Extract the archive and use the included run scripts as described below.

QEMU Installation

The emulator requires QEMU to be installed on your system.

Refer to the platform-specific instructions on the QEMU website for installation details.

Running the Emulator

After building, you will find the emulator run scripts (run.sh for Linux, run.bat for Windows) in the output images directory:

out/std_emulator/packages/phone/images

These scripts launch QEMU with the correct parameters for the Oniro Emulator.

To start the emulator, use the appropriate script for your operating system:

  • Linux:
    sudo ./run.sh

    If you encounter permission errors, ensure the script is executable:
    chmod +x run.sh

  • Windows:
    .\run.bat

    Run the script from a Command Prompt or PowerShell window with administrator rights if required.

Note for Windows Users:
The emulator requires Hyper-V to be enabled on your system.

Enabling Hyper-V on Windows

  1. Open Start Menu and search for “Turn Windows features on or off”.
  2. In the Windows Features dialog, check the boxes for:
    • Hyper-V
    • Hyper-V Management Tools
    • Hyper-V Platform
  3. Click OK and wait for the changes to apply.

Restart your system after enabling Hyper-V.

Connecting to the Emulator with HDC

Once the emulator is running, you can connect to it using HDC (the OpenHarmony Device Connector):

hdc tconn localhost:55555

This command connects your host to the emulator instance for debugging and file transfer.

Note:
hdc is included in the OpenHarmony SDK toolchain. Ensure it is in your PATH.

Reference

For additional information please refer to the Oniro Board Support Packages repository.
